High-performance LF woofer and HF compression driver * Wide frequency response for deep bass and crisp highs * Built-in high-efficiency power amplifier * Integrated DSP for optimized sound and system protection * High sound output suitable for medium to large venues * Balanced sound dispersion for wide coverage AMPLIFIER & DSP SPECIFICATIONS: • 2000W - Two Channel Class-H Amplifier • M1 Power Factor Crossover Module • Enhanced Amplifier efficiency • 3-Stage System protection process • 24-Bit Built-In DSP for Superior voicing • On-Board 2 Channel mixer Bluetooth • 2 x TRS Jack mic input, 1 x XLR line input, 1 x XLR line output & 1 x Bluetooth input • IEC mains connector HF TRANSDUCER: • 10CT 25 - 1.4" Exit HF Compression Driver • 50W AES, 200W Peak • 2.5" Voice Coil - Ferrite • Extended Frequency range • High flux density LF TRANSDUCER: • 15CT 3D - 15" Low Frequency Driver • 600W AES, 2400W Peak • 3" Copper Voice Coil - Ferrite Magnet • Enhanced Airflow Path for minimal power compression ACOUSTICAL SPECIFICATIONS: • Freq. Response (-3 dB) :55 Hz - 18 kHz • Freq. Range (-10 dB) : 40 Hz - 20 kHz • H Dispersion : 90° (- 6 dB) • V Dispersion : 50° (- 6 dB) • Crossover : 1.2 kHz Active • Max Output : 126dB, 132dB Peak
